What Are Infill Panels?

Infill panels are versatile cladding materials that can be seamlessly integrated into a structure's framework, effectively defining spaces by creating walls, dividers, and partitions.

These panels come in various materials including bricks, concrete, glass, solid metal, timber, and metal mesh, among others.

Among these materials, metal mesh is increasingly becoming a popular choice for both interior and exterior cladding projects, particularly decorative architectural wire mesh. Designers and architects favor these decorative mesh panels due to their longevity, striking ornamental features, non-combustible properties, and excellent ventilation capabilities.

How is METART-WW55 Architectural Infill Wire Mesh Panel Made?

This architectural mesh is constructed from 1.95 stainless steel wires. The warp direction features a double-wire combination, while the weft direction consists of triple-wire groups. The weaving process results in a rectangular opening measuring 4.1x6mm.

Despite its complexity, this architectural wire mesh employs a plain weave pattern, with the shute wires manually fed across the warp wires piece by piece.

Once a large wire mesh panel is fabricated, it will be precisely cut to the customer's specified dimensions to meet their requirements.

Specification Details

Features of METART-WW55 Architectural Wire Mesh

►Robust for Security Applications: This decorative wire mesh panel is exceptionally strong, featuring a 2x1.95mm warp diameter and 3x1.95mm weft diameter.

►Non-combustible:  Made from stainless steel, this material is fire-resistant. Opting for metal cladding infills ensures no fire risk and provides an added layer of safety in residential and commercial applications.

►Changeable Specifications:  Customers can adjust the wire diameter and opening size within this pattern design to meet specific application needs.

►Aesthetic Appeal: The elegant and contemporary design of the decorative metal mesh adds a unique ornamental touch to any environment, seamlessly combining security-oriented functionality with architectural style.

►Corrosion Resistant: Made from premium stainless steel, this metal mesh decorative panel offers excellent resistance to corrosion, ensuring longevity and low maintenance in regular environments.

►Easy Installation: Wire mesh screens as infill panels are always easy to install, it can be easily framed like many other infill panels.

►Safety and Security: This architectural design provides a secure metal barrier without obstructing visibility, making it perfect for areas needing both safety and open-sight lines.

How to Purchase This Pattern "METART-WW55" Architectural Mesh?

1. Specify Material and Grade: Indicate the type and grade of material you require.

2. Specify Dimensions: Provide the specific dimensions for the wire mesh sheet.

3. Confirm Orientation:  Confirm the orientation of the wire mesh, as this pattern features different wire combinations vertically and horizontally.

4. Specify Finish: Indicate the finish you would like for the mesh. Indicate Quantity: Specify the number of sheets or total area required.

5. Request a Quotation: Contact us to receive a free quotation.

6. Request a Sample:  If the price fits your budget, feel free to contact us to request a complimentary sample.
